LEMCO LFC-003 F-male compression connector

Features

• F male compression connector, EPDM O-ring sealed
• 0.3–3000 MHz frequency range, 75 Ω impedance
• Shielding effectiveness >130 dB at 30–1000 MHz, >120 dB at 1000–3000 MHz
• Very low insertion loss (<0.01 dB across the full range)
• Strong return loss (-43.4 dB to -31.1 dB)
• Brass CuZn 39Pb3 / zinc body, nickel-plated
• Max tensile strength 260N; operating temp -40°C to +100°C
• Compatible with LC-1200, LC-1401, LC-1411 cables and LTC-001/002/003/004 tools
• Compressed size 25.65 x 11mm, 9.4g net weight
• Package qty: 100 pcs
